Pro-lok Pro 19" Mixer Cases

- 19″ standard rack with mixer on top

- 10U rack space on top and usable space on the bottom, and there is another extra 2U space to
accommodate for the depth of the mixer being used on the top rack

- 9mm plywood construction with laminated plastic covering

- 35mm × 35mm aluminum section

- Heavy duty corners, heavy duty T Brackets

- Medium butterfly latches, medium recessed handles

- Attachment rails (top/front)

- Complete rack mounting component: washers, nuts and screws

- Top / front covers and rear door

- Colors: BK: Black (standard) BL: Blue / RD: Red / YW: Yellow

Model	Depth (mm)	Handles	Butterfly Latches	Casters	External Dimensions (mm)	Packaging CBM	Weight (kg)
PLOK-2MIX	508	2	5	-	545x620x287	0.128	13.5
PLOK-4MIX	508	2	5	-	545x620x376	0.163	15.5
PLOK-6MIX	508	2	5	-	545x620x465	0.197	17.5
PLOK-8MIXW	508	2	5	4	545x620x554	0.231	19.5
PLOK-10MIXW	508	4	7	4	545x620x643	0.266	26.5
PLOK-12MIXW	508	41	8	4	545x620x732	0.300	29
PLOK-14MIXW	508	4	8	4	545x620x821	0.334	31
PLOK-16MIXW	508	4	8	4	545x620x910	0.369	33
PLOK-18MIXW	508	4	8	4	545x620x999	0.403	35
PLOK-20MIXW	508	4	8	4	545x620x1088	0.437	37.5
